SURVIVE-ARC® Chino trousers, 8,7 Cal/cm² CAT 2

SURVIVE-ARC® Chino trousers, 8,7 Cal/cm² CAT 2

SURVIVE-ARC® Chino trousers, 8,7 Cal/cm² CAT 2

SURVIVE-ARC® 305g/m2 Conti trousers 12.4 cal/cm2 CAT 2

Application: Work wear for the electrical industry


Survive-ARC® HRC 2, ATPV 12.4 cal/cm2. SACTS026.
Trousers with zip front, half ruched waistband and seven belt loops.


• CHARNAUD® SURVIVE-ARC® Body protection.
• FR zip fly closure, two side slit pockets, two back jet pockets and belt loops.
• Options:
• Silver reflective tape around both legs just below knees.
• Trousers available in ladies design upon request.

Colour Navy blue or khaki.

Size XS – 4 XL; 72cm – 147cm; 28” – 58”

Materials Fabric: Permanently flame-resistant (FR) and arc rated (AR).

Application Arc flash protective work wear for the electrical industry.

Hazard Assessments Thermal effects from electric arc flash, flames and flash fires.


• Guaranteed flame-resistant for the life of the garment.
• Water washable.
• Excellent breath ability – absorbs sweat and moisture.
• Cotton comfort: cool in summer and warm in winter.

Product Standards Fabric and/or garment:

• SANS 724
• NFPA 70E
• ASTM F2621
• IEC 61482-2
• CE certified.
• ATPV¹: 12.4 cal/cm² ; HAF²: 80.2 %


Arc flash clothing is intended to provide protection from the thermal effects of arc flash and this product must be used as part of an appropriate set of PPC and PPE to protect against the hazards of arc flash. This product complies with standards that are intended to protect against arc flash in most situations that arise during normal use. There may be exceptional cases in which even the best protection is not enough to prevent the harm caused by arc flash or the related effects, although the product meets statutory and industry specifications, the use of this product does not guarantee that the product will provide complete protection in those exceptional cases. If you are in doubt or do not fully understand these limitations, contact the manufacturer for full information. The product may be returned to the supplier if you are not willing to accept a product that is subject to the limitations set out above.

¹ATPV: Arc Thermal Performance Value. The higher the value, the more insulated the user is from second degree burn.
2HAF: Heat Attenuation Factor. The higher the HAF%, the more heat is blocked by the fabric.

Product Features

  • Guaranteed flame – resistant for the life of the garment.
  • Water washable.
  • Excellent breathability – absorb sweat and moisture.
  • Cotton comfort – cool in summer and warm in winter.
  • 50% Longer wear life than traditional 100% cotton garments
